Transport Requests Test

Change and Transport System (CTS) is the tool provided by SAP for the creation, documentation and distribution of changes within a system landscape.

Using this test, administrators may figure out the number of requests that were created, how many of those requests were successful and how many succeeded with errors. In addition, you may figure out how many transport requests were partially successful and how many requests encountered critical errors. This way, administrators may figure out how well the transport requests were processed and the exact cause behind the error prone requests.

Target of the test : A SAP ABAP System

Agent deploying the test : An internal/remote agent

Outputs of the test : One set of results for every SAP ABAP System being monitored.

Configurable parameters for the test
Parameter	Description
Test Period	How often should the test be executed
Host	Host name of the server for which the test is to be configured.
PortNo	Enter the port to which the specified host listens.
Connection Type	Specify how this test should connect to the target SAP ABAP System and collect the required metrics. By default, this flag is set to Application Server indicating that the test uses the IP address of a SAP ABAP Instance connected to the target SAP ABAP System to collect the required metrics. If this flag is set to Logon Group, then, the eG agent automatically connects to the logon group, chooses any one of the available SAP ABAP Instances within the group to connect to the target SAP ABAP System and collects the required metrics.
SID	Specify the three-digit server-specific unique identification code associated with the target SAP ABAP System here. The SID helps in uniquely identifying the target SAP ABAP System.
Application Server	This parameter appears only when the Connection Type flag is set to Application Server. For the eG agent to connect to the target SAP ABAP System and collect metrics, this test should be configured with the IP address of any of the SAP ABAP Instances associated with the target SAP ABAP System. Specify such IP address in this text box.
Message Server	This parameter appears only when the Connection Type flag is set to Logon Group. Specify the IP address of the SAP Message Server to which the target SAP ABAP System is connected to.
Logon Group	This parameter appears only when the Connection Type flag is set to Logon Group. A logon group is a group of servers that belongs to one SAP system. Logon groups are used to automatically distribute user logons to individual instances or to groups of SAP instances (Applications Server). Specify the name of the logon group that should be used by the eG agent to connect to any one of the SAP ABAP Instances within the group and collect the required metrics from the target SAP ABAP System.
ClientName	Specify the ID of the client system as what the eG agent will be connecting to the SAP ABAP instance. To know how to determine the client ID to use, follow the instructions provided in Determining the Client ID/Name for the eG Agent to Connect to the SAP ABAP Instance.
SAPUser	Typically, to connect to a SAP ABAP instance and run tests, the eG agent requires the permissions of a SAP user who has been assigned with certain authorization objects. Ideally, you will have to create a new user role on the SAP ABAP instance for this purpose, associate the above-mentioned authorization objects with that role, and assign the new role to an existing SAP user. The procedure for the same has been provided in Creating a New User Role for Monitoring and Assigning it to a SAP User. Once the new role is assigned to a SAP user, specify the name of this user against SAPUser.
Password	The password of the specified SAPUser.
Confirm Password	Confirm the password by retyping it here.
SysNo	This parameter appears only if the Use SAPControl flag is set to No – i.e., if the test uses SAPJCO to collect measures. An indicator of the TCP/IP port at which the SAP server listens. For example, for a server that listens at port 3200, the SysNo will be ‘00’. Similarly, if the SAP server port is 3201, the SysNo will have to be specified as ‘01’. Therefore, in the SysNo text box specify the system number of the SAP server with which the specified client communicates. To know the system number for the ABAP server being monitored, follow the procedure detailed in Identifying the SAP Router String and System Number.
Router	This parameter appears only if the Use SAPControl flag is set to No – i.e., if the test uses SAPJCO to collect measures. If the SAP client with the specified ClientName exists in a network external to the SAP server, then a router will be used to enable the server-client communication. In such a case, specify the router string of the router in the Router text box. If both the client and the server exist in the same network, then specify ‘none’ against the Router text box. To know what is the SAP Router string for the ABAP server being monitored, follow the procedure detailed in Identifying the SAP Router String and System Number.
InstanceName	This parameter appears only if the Use SAPControl flag is set to No – i.e., if the test uses SAPJCO to collect measures. This is set to none by default. This implies that the eG agent automatically discovers the instance name at run time.
Timeout	Indicate the duration (in seconds) for which this test should wait for a response from the SAP ABAP instance. By default, this is set to 120 seconds.
JCO Version	The eG agent uses the SAP JCO library to connect to the SAP ABAP system and pull out metrics. To enable the eG agent to make this connection and query the metrics, you need to specify the version of the SAP JCO library that the agent needs to use. For instance, to instruct the eG agent to use JCO v2.1.19, it would suffice if you specify the ‘major version number’ alone against JCO Version – in the case of this example, this will be 2.x. Note that if you have downloaded the SAP JCO CONNECTOR files for SAP JCO version 3 from the SAP market place (as instructed by Downloading the SAP JCO Connector files Required for Monitoring ), then the JCO Version configuration should be 3.x.
DD Frequency	Refers to the frequency with which detailed diagnosis measures are to be generated for this test. The default is 1:1. This indicates that, by default, detailed measures will be generated every time this test runs, and also every time the test detects a problem. You can modify this frequency, if you so desire. Also, if you intend to disable the detailed diagnosis capability for this test, you can do so by specifying none against DD Frequency.
Detailed Diagnosis	To make diagnosis more efficient and accurate, the eG Enterprise embeds an optional detailed diagnostic capability. With this capability, the eG agents can be configured to run detailed, more elaborate tests as and when specific problems are detected. To enable the detailed diagnosis capability of this test for a particular server, choose the On option. To disable the capability, click on the Off option. The option to selectively enable/disable the detailed diagnosis capability will be available only if the following conditions are fulfilled: The eG manager license should allow the detailed diagnosis capability Both the normal and abnormal frequencies configured for the detailed diagnosis measures should not be 0.

Measurements made by the test
Measurement	Description	Measurement Unit	Interpretation
Total exports	Indicates the total number of requests that were created during the last measurement period.	Number
Successful exports	Indicates the number of transport requests that were successful during the last measurement period.	Number	The TPALOG return code for these requests is 0000.
Succeeded with warnings	Indicates the number of transport requests that succeeded with warnings during the last measurement period.	Number	The TPALOG return code for these requests is 0004. Warnings could be innocuous as in regular warnings issued when the transport request involves object deletion. Nevertheless, these warnings need to be checked.
Partial successes	Indicates the number of transport requests that were partially successful during the last measurement period.	Parts/sec	The TPALOG return code for these requests is 0008. These errors need to be analyzed and corrected. Examples of such errors include original/repaired objects not being overwritten. Detailed diagnosis for this measure provides details of these requests such as : Request timestamp, Request number, target system, source client, transport step, project number, transport user and transport admin.
Percentage of partial successes	Indicates the percentage of transport requests that were partially successful during the last measurement period.	Percent	The TPALOG return code for these requests is 0008. Typically these errors arise due to transport request configuration as opposed to a transport system error.
Critical errors	Indicates the number of transport requests with critical errors during the last measurement period.	Number	The TPALOG return code for these requests is 0012 or higher. These errors usually arise due to some serious error in the transport system and hence tend to impact a majority of the transport requests. The detailed diagnosis of this measure if enabled lists the details of these requests such as Request timestamp, Request number, target system, source client, transport step, project number, transport user and transport admin.
Percentage of critical errors	Indicates the percentage of transport requests with critical errors during the last measurement period.	Percent	The TPALOG return code for these requests is 0012 or higher. These errors tend to correspond to the overall availability of the transport system.
